The N9K-C9336C-FX2 is a Cisco Nexus 9300-FX2 1RU high-density spine/leaf switch delivering 7.2 Tbps switching with 36x 40/100G QSFP28 ports — supporting MACsec, VXLAN, EVPN, MPLS, and both NX-OS and ACI modes for cloud-scale and enterprise data center deployments.
36x 40/100G QSFP28 Ports | 7.2 Tbps Switching | 2.4 Bpps Forwarding | 40MB Buffer | MACsec | VXLAN + EVPN | MPLS | NX-OS + ACI | Cloud Scale ASIC | Breakout on All Ports | 1U Rack
Specifications:
Brand: Cisco | Model: N9K-C9336C-FX2 | Series: Nexus 9300-FX2 | Ports: 36x 40/100G QSFP28 | Switching Capacity: 7.2 Tbps | Forwarding Rate: 2.4 Bpps | Buffer: 40MB | USB: 1 | Management: 1x OOB RJ45 + 1x OOB SFP+ | Console: 1x RJ45 | Form Factor: 1U Rack | Airflow: Port-side Intake or Exhaust (selectable)
Breakout:
All 36 QSFP28 ports support: 4x10G | 4x25G | 2x50G
Scalability:
VLANs: 3,967 | VRF Instances: 16,000 | Port Channels: 512 | ECMP Paths: 64 | MSTP Instances: 64 | IGMP Groups: 32,000 | Multicast Routes: 32,000 | ACL Ingress: 5,000 | ACL Egress: 2,000
L3 Features:
BGP | OSPF | EIGRP | RIP/RIP-2 | PIM-SM | MSDP | MPLS | ECMP | VXLAN + EVPN | HSRP | VRRP | SSM
L2 Features:
802.1Q VLAN | MSTP | STP | RPVST+ | vPC | LACP | MACsec (IEEE 802.1AE)
Security:
MACsec | ACL | CoPP | RBAC | SSH | Trust Anchor Module | DHCP Snooping
Automation:
NX-OS | ACI Mode | POAP | Python | NX-API | RESTCONF/NETCONF | Streaming Telemetry | Nexus Data Broker
High Availability:
Dual Hot-Swap PSU (750W) | Modular Fan Trays | Reversible Airflow
